Heraeus Vötsch Temperature Testing Chamber 190 Liters Temp. -70°C to +180°C VTS 7018-5

Heraeus Vötsch

Type: VTS 7018-5

Heraeus Vötsch Temperature Test Chamber Water-Cooled

Temperature Range -70°C to +180°C

Temporal Temperature Deviation ± 0.1 to ± 0.5 K
Spatial Temperature Deviation ± 0.5 to ± 2.0 K

Cooling Temperature Change Rate 7.5 K/min
Heating Temperature Change Rate 7.5 K/min

Heat Compensation +20°C 3000 W
Heat Compensation -20°C 3000 W

Test Chamber Dimensions: Width 580 mm Depth 450 mm Height 750 mm
External Dimensions: Width 870 mm Depth 1280 mm Height 1575 mm

Observation Window:

Width 300 mm x Height 540 mm

Test Chamber Volume 190 Liters

Nominal Voltage: 3/N/PE AC, 400V ±10 %, 50Hz
Nominal Power: 10.5 kW Nominal Current: 22 A
Fuse, site-specific: 32 A slow-blow

Sound Level at 1m Distance (Free Field Measurement) < 69dB (A)

Side Entry 50 cm / 125 cm

Cabinet is Water-Cooled

Refrigerant: R 404A and R 23

Weight approx. 460 kg

For your safety as a buyer, the following information!

The following points will be carried out on our offered chambers in advance:
1. Function check and replacement of necessary components
2. If necessary, new filling with legally compliant refrigerant
3. Leak test with certificate
4. After successful inspection, the chambers will undergo a documented test run.

Condition: used

Scope of Delivery: (See Image)

(Changes and errors in the technical data are reserved!)

We would be happy to answer any further questions by phone.
